Digital Distribution Panel (P/N 9800-3782)
Our Digital Single Pipe Panel is supplied with one Dual Digital Panel Meter, a Flow Finder (either 0-47.5 SCFH or 0-95 SCFH, depending upon ordering selection), a High Resolution Flow or Dual (pressure/flow) Transducer, a shutoff valve, and a precision pressure regulator.
Ordering Information
Please note that a part number, range, fitting and TD Type designation is required for each panel when ordering.
| PART NUMBER |
RANGE* |
FITTING** |
TD TYPES*** |
| 9800-3782 |
L, M, H, C |
BS |
1, 2 |
| * Flow Finder Ranges: |
| L |
Low: input = 19.0 SCFH, Output = 9.5 SCFH |
| M |
Medium: Input = 47.5 SCFH, Output = 9.5 SCFH (Recommended) |
| H |
High: Input = 95.0 SCFH, Output = 19.0 SCFH |
| C |
Custom: Multiple output ranges to meet customer specifications. |
| ** Fitting: |
| BS |
Manifolds supplied with nickel-plated brass, standard tubing connectors. For use with standard 3/8" inch plastic tubing. |
| *** TD Types |
| 1 |
High Resolution Flow Transducer |
| 2 |
High Resolution Dual Transducer (Recommended) |
Ordering Example:
If you ordered Part No. 9800-3782H-BS-2, for example, you would receive a Digital Distribution Panel equipped with 0-19 SCFH flow ranges in each of the manifold outports and a 0-95 SCFH Flow Finder that measures regulated air flow from the central office dryer(s). This panel would also include a High Resolution Dual Transducer and nickel-plated brass tubing connectors on each manifolds outgoing ports Standard equipment would also include one dual digital panel meter.
Please refer to our product
data sheet for additional information about the Digital Panels. Pricing information can be obtained from your Purchasing Department or by calling System Studies Incorporated at 800-247-8255.
